ESP32D NodeMCU ESP-WROOM-32D Wi-Fi and Bluetooth Module Dual Core Consumption ไม่มีช่องต่อเสาอากาศ

• ตำแหน่งขา และระยะขาเหมือนกับ ESP-WROOM-32
• ภายในใช้ชิป ESP32-D0WD
• ขนาด 18 * 19.2 มิลิเมตร

product features

WiFi .1 WiFi

• 802.11 b / g / n / e / i
• 802.11 n ( 2.4 GHz ) at speeds up to 150 Mbps
• 802.11 e : QoS mechanism to implement wireless multimedia technology
• WMM-PS, UAPSD
• A-MPDU and A-MSDU frame aggregation techniques
• Block reply
• Fragmentation and reorganization
• Beacon automatic monitoring / scanning
• 802.11 i security features: pre- authentication and TSN
• Support WPA / WPA2 / WPA2-Enterprise / WPS encryption
• Infrastructure Network ( Infrastructure BSS ) Station mode / SoftAP mode
• Wi-Fi Direct ( P2P ), P2P discovery, P2P GO mode, and P2P power management
• UMA compatible and certified
• Antenna diversity and selection

Bluetooth 2 Bluetooth
•  Bluetooth v4.2  complete standards including traditional Bluetooth ( BR / EDR ) and Bluetooth low energy ( BLE )
•  Supports standard Class-1 , Class-2  and Class-3 , without the need for an external power amplifier
•  strengthen the precise power control
•  the output power up to +  10 dBm
• NZIF  receiver with -98 dBm  of BLE  receiver sensitivity
•  adaptive Frequency hopping ( AFH )
•  based on the SDIO  /  the SPI  /  the UART  standard interface of the HCI
•  speeds up to 4 Mbps  speed the UART the HCI
•  support BT 4. 2 controller and host  protocol stack
•  Service Discovery Protocol ( SDP )
•  Universal Access Application ( GAP )
•  Security Management Protocol ( SMP )
•  Low Power Bluetooth
• ATT  /  GATT
• HID
•  Supports all GATT-  based low-power Bluetooth applications
• SPP-Like  low-power Bluetooth transmission protocol data through
• the BLE the Beacon
• the A2DP  /  AVRCP  /  the SPP, HSP  /  HFP, the RFCOMM
• the CVSD and SBC audio codec algorithm
• Bluetooth piconet ( piconet ) and scatternet ( scatternet )RFCOMM • CVSD  and SBC audio codec algorithms •  Bluetooth piconet ( Piconet ) and scattering Network (Scatternet )

CPU and storage
• Xtensa® 32-bit LX6 dual-core processor with computing power up to 600 DMIPS
• 448 KByte ROM
• 520 KByte SRAM
• RTC in 16 KByte SRAM
• QSPI can connect up to 4 Ge Flash / SRAM , each Flash up to 16 MBytes
• Supply voltage: 2.2V to 3.6V

clock and timer
• Built-in 8 MHz oscillator, support self-calibration
• Built-in RC oscillator for self-calibration
• Supports external 2 MHz to 40 MHz crystal
• Supports external 32 kHz crystal for RTC , supports self-calibration
• 2 timers groups, each group including 2 th 64-bit general-purpose timers and . 1main system watchdog
• RTC timers with sub-second precision
• RTC watchdog

Peripheral interface
Bit SAR-12 is the ADC • , up to 18 is channels
• 2 th 8-bit D / A converter
• 10 touch sensors
• Temperature sensor
• 4 th the SPI
• 2 th the I2S
• 2 th the I2C
•. 3 th the UART
•. 1 th the SD the Host / the eMMC / the SDIO
•. 1 th the Slave the SDIO / the SPI
• with dedicated DMA Ethernet MAC interface that supports the IEEE 1588
• 2 the CAN.0
• IR ( TX / RX )
• Motor PWM
• LED PWM , up to 16 channels
• Hall sensor
• Ultra low power front analogue amplifier

2.6 security mechanism .6 security mechanism

• Supports all IEEE 802.11 security features, including WFA , WPA / WPA2 and WAPI
• Secure boot
• Flash encryption

• 1024-bit OTP , up to 768 bits available
• Encrypted hardware accelerator:

 - AES
    - HASH ( SHA-2 ) library
    - RSA
    - ECC
    - random number generator ( RNG )

2.7 Application

• Universal low power IoT sensor hub

• Universal low power IoT recorder
• Video streaming of the camera
• OTT TV case / set-top box device
• Music player
    - Network music player
    - Audio streaming media device
• Wi-Fi toy
    - Counter
    - toy antiplayer
• Wi- Fi Speech Recognition Equipment
• Headsets
• Smart Sockets
• Home Automation
• Mesh Networks
• Industrial Wireless Control
• Baby Monitor
• Wearable Electronics
• Wi-Fi Location Awareness Equipment
• Security ID tag
• Healthcare
    - motion monitoring and anti-lost alarm
    - temperature recorder

ESP-32/32S module main parameters

parameter table
